AMG750-1G-4G-1U4
5060811140987
Industrial 4G/LTE Cat4 EU Router 4 x 10/100/1000Base-T(x) RJ45 Ports, 1 x 10/100/1000Base-T(x) RJ45 WAN Port, WiFi, RS232/485 Serial, Dual SIM, DIN Rail / Wall Mount, -40°C to +75°C, 12-56VDC Power Input
(Verizon, AT&T, PTCRB Certified)
Features
- 2G/3G/4G/LTE Cat4 Cellular modem with Dual SIM card and fail-over support
- Gigabit Ethernet WAN port supports load balancing or fail-over applications
- 2.4/5GHz Dual Band WiFi Radio 802.11 a/b/g/n/ac
- Dual Power Inputs with 12-56 VDC support
- RS232/485 serial data channel for legacy equipment
- USB port supports remote data logging
- Layer 3 support including static and dynamic routing RIP v1/v2, OSPF, BGP
- VPN tunneling supports IPsec, Open VPN, PPTP, L2TP and GRE with up to 16 independent tunnels
- AMG Lifetime Support Warranty
Product Status
Active
Note: This product includes paddle antennas for Cellular & WiFi in the box. These antennas are not designed for external operation. When the unit is installed in a cabinet or other such location refer to the Antennas tab above for compatible options.
The AMG750 series Industrial Cellular Managed Router provides 5 x Gigabit Ethernet ports. 1 x Gigabit Ethernet port provides a configurable WAN connection while 4 x Gigabit Ethernet ports provide connection for remote devices and optional IEEE 802.3at 30W PoE+ support.
An integrated dual SIM 4G/LTE Cat4 modem provides connection in remote deployment scenarios where a wired connection is not available and combined with the wired WAN port can also act in fail-over or load balancing modes. (Verizon, AT&T, PTCRB Certified)
A dual band 2.4/5GHz wireless connection is also provided for local wifi access and supports 802.11 a/b/g/n/ac as well as a USB port supporting device logging functions. An RS232 or RS485 channel is provided to allow legacy serial data equipment to be connected at remote locations as well as a digital input and relay output for device monitoring and control applications.
Dual power supply inputs are provided for the highest levels of system operation with a wide input range of 12-48 VDC supported on non-PoE models. PoE models feature voltage boosting technology ensuring that reliable PoE can be supplied to all 4 Ethernet ports when being powered by 24-56 VDC sources.
The USA models are fully Verizon, AT&T and PTCRB Certified.
Product Features
.png)
WiFi Mode
AP Router
WDS Only
WDS Hybrid Modes
WAN
Cellular
Ether-WAN
Failover
Load Balance
Cellular
3GPP
2G/3G/4G IP Passthrough
IPv4/6
Ether-WAN
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Network Monitor
ICMP/DNS Query
WiFi Functions
Multi-SSID
WMM
WiFi Security
WEP
WPA
WPA2
WPA-PSK
WPA2-PSK
802.1x
Virtual COM
RFC2217
TCP Client
TCP Server
UDP
Modbus
Gateway for Modbus TCP/ RTU / ASCII Master/Slave
Access: Slave for Device Status/Information Access
Data Logging
Sniffer
Off-Line / Full-Time Proxy
Mixed Modes
I/O
1 x Digital Input (Logic 0: 0~2V
Logic 1: 5~30V)
1 x Relay Output (30V @ 1A)
MTBF (Hours)
198062
Power Consumption (W)
15.6
Power Inputs
2
Power Interface
8 Pin Removable Terminal Block
Input 1 Voltage
12-56 VDC
Input 2 Voltage
12-56 VDC
Heat Dissipation at Max Load (BTU/h)
53
Operating Temperature
-40°C to +75°C
Storage Temperature
-40°C to +85°C
Recommended PSUs
AMGPSU-W12-P25 (25W 12VDC)
AMGPSU-I12-P24A (24W 12VDC)
IP Rating
IP40
Product Class
Industrial Grade
Warranty
AMG Lifetime Warranty
Compliance
NDAA Compliant
TAA Compliant
Scheduling
Time Schedule List
Grouping
Host Grouping List
Ext. Server
Email
Syslog
RADIUS
SCEP
FTP
DDNS
IGMP
Certificate
My Certificate
Trusted Certificate
Issue Certificate
Cellular Toolkit
Data Usage
SMS
SIM PIN
USSD
Network Scan
Event Handling
User Defined Manage/Notify Event; Action & Trigger by SMS
Mail
Syslog
SNMP
VPN Tunneling
IPsec
Open VPN
PPTP
L2TP
GRE
Scenario
Site/Host to Site/Host
Hub & Spoke
Dynamic VPN
VPN Capability
IPsec: up to 16 Tunnels
Firewall
SPI Firewall with Stealth Mode
IPS
Access Control
Packet Filter
URL Blocking
MAC Filter
Configuration
Web GUI
CLI & Command Script
Management
SNMPv3 Std & AMG MIB
TR069
System
Upgrade
Backup & Restore
Reboot & Reset
Syslog
FTP
FTP Server & User Account
Diagnostic
Packet Analyser & Diagnostic Tools
Dimension Drawing (mm)
Dimensions
Width = 51 (mm) / 2.01 (in)
Depth = 120 (mm) / 4.72 (in)
Height = 160 (mm) / 6.3 (in)
Depth = 120 (mm) / 4.72 (in)
Height = 160 (mm) / 6.3 (in)
